ENDO Stainless Steel Spring Balancer (EWF-120X) 105-120 kg
Price
2.188,00 EUR
Available — ships in 5–7 working days
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
Spring Balancers for Food Industry
Volume pricing — save up to 12%
Discount is calculated automatically on the cart subtotal.
| Quantity | Discount |
|---|---|
| 1 unit | — |
| 2 | −3% |
| 3–4 | −5% |
| 5–9 | −8% |
| 10+ | −12% |
+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.
Need a tailored offer?
Send us your requirements through the quote form — this product will be prefilled and you can add more items in one request.
Japanese-made stainless spring balancer for the food industry and sensitive assembly, with a 105-120 kg working range, 2 m cable run and food-grade H1 lubrication in a polished aluminium housing.
Key features
- For tool holding in the food industry and contamination-sensitive assembly
- Brushed and polished aluminium housing and cover (unpainted)
- Stainless steel bottom hook, pins, rivets, bolts and screws
- Food-grade (class H1) synthetic grease
- Drum lock mechanism for safe tool changes
- Fall-arrest device stops the tool in the unlikely event of spring failure
- Plug-type cable set — cable replacement without disassembling the balancer
- CE marked, made in Japan
Technical overview
- Model / SKU: EWF-120X
- Product family: Spring Balancers for Food Industry
- Working load range: 105 - 120kg
- Cable length: 2 m
- Cable diameter: 4,76 mm
Order online or send a quote request for delivery terms and customer-specific configurations.
What it is for
- Stainless/washdown balancer for tools in food, pharma and wet areas.
- Meat processing, dairy, cleanrooms.
This model
Stainless steel: food, pharma, chemical and washdown areas. Balancer: tool/part weight must be inside the min–max range. Spring balancer: hand tools; not a hoist.
Check before you choose
- Tool weight range
- Corrosion class / washdown
- Cable travel
Not suitable for
- Dry workshops where standard models suffice
Before you order Technical check — we confirm a few parameters and compatibility with you before the order.
To confirm the right configuration we will ask you:
- Total suspended mass: tool + adapters + the part of hose/cable the balancer carries? Any mass change during work? Mass must be inside the working range; an oversized balancer gives too much return force, an undersized one sinks.
- Cable stroke needed; mounting height; highest and lowest working point? Stroke must cover the working range.
- Food/pharma requirement; washdown regime: agents, concentrations, temperature; hygiene regime; chlorides? Stainless is not automatically resistant to all chemicals; parts that are not stainless matter.
Typical mistakes to avoid
- Stainless ≠ resistant to everything — check the washing regime and agents.
Helpful to have ready: Washing process · Chemicals · Mass/stroke · Temperature
Attributes
| Working load range | 105 - 120 kg |
|---|---|
| Cable length | 2 m |
| Cable diameter | 4.76 mm |
