Heavy-Duty Electric Pallet Truck (EPV30-P) 3000 kg
Price
7.615,00 EUR
From 6.092,00 EUR
Sale
Direct factory order
— −20% · 16–20 weeks · 40% deposit
Direct factory order — save 20%
Produced to order at the manufacturer’s plant and shipped directly — the factory discount is already included in the price shown.
- Production & delivery: 16–20 weeks
- Deposit at order: 40%
- Balance: 60% before dispatch or collection
Factory-order prices are outside the automatic volume and bundle discount programme. Because production and sea freight are scheduled months ahead, we reserve the right to adjust the balance in the event of significant exchange-rate or container-freight cost changes before dispatch — we will always contact you first. B2B sales only.
Select configuration
Choose attribute values to resolve the exact variant, SKU and price.
Choose all attributes to lock a variant.
Direct factory order (made to order)
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
Electric Pallet Trucks
Need a tailored offer?
Send us your requirements through the quote form — this product will be prefilled and you can add more items in one request.
Innovative heavy-duty rider pallet truck with 3000 kg capacity, AC control system, speed-sensing platform and roll-out side battery — built for high-speed load transport and loading-dock work.
Key features
- 3000 kg capacity for heavy-duty pallet moving
- AC control system without motor brushes or directional contactors
- Multi-function display: hour meter, fault code, battery condition
- Side-way battery with roll-out device for quick replacement
- Speed sensor in the platform ensures driving safety
- Built-in pressure relief valve prevents overloads
- Braking in both upright and horizontal handle positions
Technical overview
- Model / SKU: EPV30-P
- Product family: Electric Pallet Trucks
- Load capacity: 3000 kg
- Engine type: AC
- Load center: 600 mm
- Load distance, center of drive axle to fork: 914/964/1034mm
- Fork height, lowered: 82 mm
- Tyre size, front: 250x80mm
- Tyre size, rear: 82x126(98)mm
- Additional wheels (dimensions): 127x57mm
- Number of wheels, front/rear (x=driving) Φ: 1X+2(2/4)
- Max. lift height: 202 mm
- Height of tiller min/max: 1150/1430mm
- Overall length: 1785/1835/1905mm
- Length to face of forks: 685 mm
- Overall width: 775 mm
- Fork dimensions: 54x180x1100mm (1150/1220)
- Width overall forks: 520/550/650/685mm
- Aisle width for pallets 1000x1200mm: 2435/2480/2550mm
- Aisle width for pallets 800x1200mm: 2320/2345/2380mm
- Turning radius: 1550/1600/1670mm
- Travel speed, laden/unladen: 9.0/9.2km/h
- Initial lift: no
- Folding platform: yes
- Electric power steering: yes
- Battery type/voltage/capacity: LA/24/240, LA/24/400, LFP/24/125, LFP/24/225
- Battery weight: 275 kg
- Battery dimensions (I/W/H): 650x247x505(535)mm
- Service weight (with battery): 780 kg
Order online or send a quote request for delivery terms and customer-specific configurations.
What it is for
- Powered horizontal transport of pallets over longer distances and higher frequency than hand trucks.
- Loading/unloading trucks, cross-docking, supermarket back-of-house.
- Rider (platform/seated) versions for long routes; double-decker for two pallets.
This model
Heavy duty: reinforced frame for the heaviest loads and intensive use. Capacity options: 3000 kg. Battery: LA/24/240, LA/24/400, LFP/24/125, LFP/24/225. Drive: AC. Initial lift: no. Folding platform: yes. Power steering: yes. Fork dimensions: 54x180x1100mm (1150/1220). Turning radius: 1550/1600/1670mm.
Check before you choose
- Capacity 1 500–3 000 kg
- Walkie vs. platform/stand-on vs. seated by distance and shifts
- Battery type (Li-ion for opportunity charging), charger
- Fork length for 1 or 2 pallets
- Ramps and gradients (drive motor power)
- Aisle width
Not suitable for
- Lifting onto racking (lift ~120–200 mm) — use a stacker
- Outdoor rough terrain
Before you order Technical check — we confirm a few parameters and compatibility with you before the order.
To confirm the right configuration we will ask you:
- Heaviest load including pallet, packaging and any attachment? Rule of thumb: use at most 80 % of rated capacity for safety and service life.
- Pallet sizes; one or two pallets per trip; fork length?
- Distance per trip and pallets per hour? Decides pedestrian vs. platform vs. seated.
- Are there gradients (ramps, slopes) in the working area? How steep (%) and how long (m)? Pedestrian and stand-on trucks are designed for level floors; motor, brakes and drive-wheel traction are sized for occasional short ramps. On a long or steep slope they overheat, lose traction or cannot hold the load.
- What is the floor: industrial concrete, asphalt, paving, gravel, uneven, potholes, sharp edges, expansion joints, thresholds, drains? Small polyurethane wheels and no suspension: tolerance for unevenness is very low. Sharp edges cut the PU tread; gaps stop the small load rollers.
- How long must the truck run continuously, how many hours per day and shifts? Pallets per hour, distance per trip? Battery capacity and truck class follow from this. Most buyers under-specify on price and end up with a truck that stops mid-shift.
Typical mistakes to avoid
- A small walkie is no substitute for a rider truck on long routes — choose the operator position by distance and intensity.
Helpful to have ready: Mass/pallet · Average and max distance · Pallets per hour · Gradients · Shifts · Charging
Attributes
| Battery type/voltage/capacity | LFP/24/125, LFP/24/225, LA/24/240, LA/24/400 |
|---|---|
| Load capacity | 3000 kg |
| Engine type | AC |
| Load center | 600 mm |
| Load distance, center of drive axle to fork | 914/964/1034 mm |
| Lowered fork height | 82 mm |
| Tyre size, front | 250x80 mm |
| Tyre size, rear | 82x126(98)mm |
| Additional wheels (dimensions) | 127x57 mm |
| Number of wheels, front/rear (x=driving) Φ | 1X+2(2/4) |
| Lift height | 202 mm |
| Height of tiller min/max | 1150/1430 mm |
| Overall length | 1785/1835/1905 mm |
| Length to face of forks | 685 mm |
| Overall width | 775 mm |
| Fork dimensions | 54x180x1100 mm (1150/1220) |
| Width overall forks | 520/550/650/685 mm |
| Aisle width for pallets 1000x1200mm | 2435/2480/2550 mm |
| Aisle width for pallets 800x1200mm | 2320/2345/2380 mm |
| Turning radius | 1550/1600/1670 mm |
| Travel speed, laden/unladen | 9.0/9.2 km/h |
| Initial lift | no |
| Folding platform | yes |
| Electric power steering | yes |
| Battery weight | 275 kg |
| Battery dimensions (I/W/H) | 650x247x505(535)mm |
| Service weight | 780 kg |
