Electric Walkie Pallet Stacker (EVV10/EVV12/EVV15) 1000-1500 kg 1600-5600 mm
Price
From 8.550,00 EUR
Direct factory order
— 16–20 weeks · 40% deposit
Direct factory order
Produced to order at the manufacturer’s plant and shipped directly — the factory discount is already included in the price shown.
- Production & delivery: 16–20 weeks
- Deposit at order: 40%
- Balance: 60% before dispatch or collection
Factory-order prices are outside the automatic volume and bundle discount programme. Because production and sea freight are scheduled months ahead, we reserve the right to adjust the balance in the event of significant exchange-rate or container-freight cost changes before dispatch — we will always contact you first. B2B sales only.
Select configuration
Choose attribute values to resolve the exact variant, SKU and price.
Choose all attributes to lock a variant.
Direct factory order (made to order)
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
Full Electric Stackers
Need a tailored offer?
Send us your requirements through the quote form — this product will be prefilled and you can add more items in one request.
Full electric walkie pallet stacker with 1000-1500 kg capacity and 1600-5600 mm lift height, AC drive with regenerative braking, stepless speed control and emergency reversing device.
Key features
- Modern AC control system with regenerative braking
- Multi-function display with hour meter and battery discharge indicator (BDI)
- Emergency reversing device and emergency power disconnect
- Stepless speed control with automatic deceleration
- Built-in pressure relief valve protects the truck against overloads
- Lifting limit switch shuts off the pump motor at maximum lift height
- Water-proof and dust-proof vertical drive motor with small turning radius
- Dividable, exchangeable mast and frame
Technical overview
- Model / SKU: EVV10_EVV12_EVV15
- Product family: Full Electric Stackers
- Load capacity: 1000 kg, 1200 kg, 1500 kg
- Lift height: 1600 mm, 2500 mm, 3000 mm, 3300 mm, 3500 mm, 4500 mm, 5000 mm, 5600 mm
- Initial lift: no
- Engine type: AC
- Folding platform: no
- Electric power steering: no
- Battery type/voltage/capacity: GEL/24/120, LA/24/200, LA/24/240, LA/24/300, LFP/24/125, LFP/24/225
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 1500 kg |
|---|---|
| Lift height | 3500 mm, 4500 mm |
| Battery type/voltage/capacity | LFP/24/125 |
| Initial lift | no |
| Engine type | AC |
| Folding platform | no |
| Electric power steering | no |
