Compact electric straddle pallet stacker with 1000-1500 kg capacity and 1600-3000 mm lift height, straddle legs for closed and special pallets, GEL or Li-ion battery and a low-gravity four-point chassis.
Key features
- Super-light walkie stacker with a very small turning radius
- Maintenance-free GEL battery (Li-ion LFP optional) with built-in charger
- Low-gravity four-point chassis design improves truck stability
- Compact design with a small footprint provides a great view
- Back-cover design makes assembly and maintenance simple
- Motor and brake are very simple to replace
Technical overview
- Model / SKU: EVV10B-PV_EVV12B-PV_EVV15B-PV
- Product family: Full Electric Stackers
- Load capacity: 1000 kg, 1200 kg, 1500 kg
- Lift height: 1600 mm, 2500 mm, 3000 mm
- Initial lift: no
- Engine type: DC
- Folding platform: no
- Electric power steering: no
- Battery type/voltage/capacity: GEL/24/105, LFP/24/100
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 1000 kg, 1200 kg, 1500 kg |
|---|---|
| Lift height | 1600 mm, 2500 mm, 3000 mm |
| Initial lift | no |
| Engine type | DC |
| Folding platform | no |
| Electric power steering | no |
| Battery type/voltage/capacity | GEL/24/105, LFP/24/100 |
