H-Beam Spreader (Fixed) (FNHG) 1000-10000 kg
Designed and tested to: EN 13155
Back to catalog

H-Beam Spreader (Fixed) (FNHG) 1000-10000 kg

SKU root: FNHG | Market: EN | Locale: en
Price Configure your crane below — live price, weight and shipping update as you choose.
Product brochure (PDF) User manual (PDF)
Categories: Modular Spreader Beams (Traverses)
Tags: Below-the-Hook Devices, Spreader Beams
Volume pricing — save up to 12% Discount is calculated automatically on the cart subtotal.
QuantityDiscount
1 unit —
2 −3%
3–4 −5%
5–9 −8%
10+ −12%

+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.

Configure your crane

Select capacity, span and options. Price, weight and shipping update live.

1 Max capacity — kg
2 Configuration —
3 Hooks

The beam can be supplied complete with articulated rotating hooks (forged safety latches), or without hooks if you attach your own rigging to the lifting eyes.

4 Paint finish

Shot blasting SA 2.5 + 60 µm polyester powder paint, RAL 1028 yellow (C2, indoor) is standard. Outdoor finishes are applied on an epoxy primer.

Need a tailored offer?

Send us your requirements through the quote form — this product will be prefilled and you can add more items in one request.

Request a quote

Fixed H-beam spreader (lifting traverse) type FNHG — a cross/H frame with four articulated rotating hooks for balanced four-point lifting with reduced headroom. Choose the beam configuration to suit the load. Manufactured to NF EN 13155 (FEM 5).

Key features

  • H-frame (cross) layout with four articulated rotating hooks and forged safety latches; reduced headroom
  • Hooks positioned by the chosen layout for balanced multi-point pick-up
  • Tear-resistant eyelet for use with synthetic slings, cables, etc.
  • No structural weld; manufactured to NF EN 13155, group FEM 5
  • Protection: grinding SA 2.5 + 60 µm C2 polyester powder paint, RAL 1028 yellow finish
  • Delivered with user / maintenance manual and CE declaration of conformity
  • Packed under shrink film for road transport (not suitable for sea freight)

Technical overview

  • Model / SKU: FNHG
  • Product family: Spreader Beams — fixed steel H-beam
  • Material: steel
  • Load capacity: 1000–10000 kg
  • Configurations: six beam layouts (1×1–4×2)
  • Standard: EN 13155 (group FEM 5)
  • Finish: RAL 1028 yellow (C2)

Choose the capacity and beam configuration to get a price, then add the product to the quote list for delivery terms and customer-specific configurations.
