Semi-Electric Straddle Stacker (PEVV10-DPV/PEVV15-DPV) 1000-1500 kg 1600-3500 mm
Price
From 3.120,00 EUR
From 2.496,00 EUR
Sale
Direct factory order
— −20% · 16–20 weeks · 40% deposit
Direct factory order — save 20%
Produced to order at the manufacturer’s plant and shipped directly — the factory discount is already included in the price shown.
- Production & delivery: 16–20 weeks
- Deposit at order: 40%
- Balance: 60% before dispatch or collection
Factory-order prices are outside the automatic volume and bundle discount programme. Because production and sea freight are scheduled months ahead, we reserve the right to adjust the balance in the event of significant exchange-rate or container-freight cost changes before dispatch — we will always contact you first. B2B sales only.
Select configuration
Choose attribute values to resolve the exact variant, SKU and price.
Choose all attributes to lock a variant.
Direct factory order (made to order)
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
Semi-Electric Stackers
Need a tailored offer?
Send us your requirements through the quote form — this product will be prefilled and you can add more items in one request.
Semi-electric straddle stacker with 1000-1500 kg capacity, 1600-3500 mm lift height and adjustable straddle legs, with explosion-proof valve, over-discharge battery protection and chain-assisted steering.
Key features
- Straddle legs with adjustable overall-type forks for closed pallets
- Electric lifting with manual travel — a cost-effective warehouse solution
- Handle-castor chain-assist steering greatly reduces labour intensity
- Explosion-proof valve guards against fork drops and protects the user
- Over-discharge protection device greatly prolongs battery lifetime
- Easy-operating foot brake
Technical overview
- Model / SKU: PEVV10-DPV_PEVV15-DPV
- Product family: Semi-Electric Stackers
- Load capacity: 1000 kg, 1500 kg
- Lift height: 1600 mm, 2500 mm, 3000 mm, 3300 mm, 3500 mm
- Initial lift: no
- Engine type: DC
- Folding platform: no
- Electric power steering: no
- Battery type/voltage/capacity: GEL/12/120, GEL/24/120
Order online or send a quote request for delivery terms and customer-specific configurations.
What it is for
- Electric lift, manual push — stacking to ~3.5 m where travel distances are short.
- Small warehouses, workshops upgrading from manual.
This model
Straddle legs: for closed-bottom / CHEP pallets and mixed pallet types; needs a slightly wider aisle. Capacity options: 1000 kg, 1500 kg. Lift heights: 1600 mm, 2500 mm, 3000 mm, 3300 mm, 3500 mm. Battery: GEL/12/120, GEL/24/120. Drive: DC. Initial lift: no. Folding platform: no. Power steering: no.
Check before you choose
- Capacity and lift height
- Pallet type (straddle option)
- Travel distance short enough to push by hand
Not suitable for
- Long routes, ramps, multi-shift
Before you order Technical check — we confirm a few parameters and compatibility with you before the order.
To confirm the right configuration we will ask you:
- Heaviest load including pallet, packaging and any attachment? Rule of thumb: use at most 80 % of rated capacity for safety and service life.
- How high must the load be lifted — top rack beam, vehicle bed, machine table? How many rack levels? Capacity at maximum height is much lower than nominal (residual capacity). Customers know 'the rack', not millimetres — ask them to measure the top beam.
- Is the load always on a EUR pallet (open bottom)? Or CHEP / closed-bottom / plastic pallets, boxes, or goods placed directly on the forks? Dimensions of the pallet underside? Forks with support legs underneath need an open-bottom pallet. Goods without a pallet load the forks at points and bend them. Pallet compatibility matters more than capacity.
- Lowest passage in the working area (doors, beams, pipes, mezzanine, container, lift)? Ceiling height where stacking happens? Lowered mast height must pass every obstacle; extended mast must fit under ceiling, lighting and sprinklers.
- What is the floor: industrial concrete, asphalt, paving, gravel, uneven, potholes, sharp edges, expansion joints, thresholds, drains? Small polyurethane wheels and no suspension: tolerance for unevenness is very low. Sharp edges cut the PU tread; gaps stop the small load rollers.
- Cycles per day, battery/charger, socket, manual pushing distance, gradients? Electric lift only — travel is manual; not for long routes or significant slopes.
Typical mistakes to avoid
- Only lifting is electric; travel is manual — not a solution for long routes or significant gradients.
Helpful to have ready: Mass · Height · Pallet · Cycles · Distance · Floor · Charging
Attributes
| Load capacity | 1000 kg, 1500 kg |
|---|---|
| Lift height | 1600 mm, 2500 mm, 3000 mm, 3300 mm, 3500 mm |
| Initial lift | no |
| Engine type | DC |
| Folding platform | no |
| Electric power steering | no |
| Battery type/voltage/capacity | GEL/12/120, GEL/24/120 |
