Designed and tested to: EN 13001-1 EN 13001-2 EN 13001-3-1 EN 14492-2

Back to catalog

Low-Profile Wall Jib Crane (NZD) 150-4000 kg 2-7 m

SKU root: NZD | Market: EN | Locale: en

Price Configure your crane below — live price, weight and shipping update as you choose.

Product brochure (PDF) Installation manual (PDF)

Categories: Wall Jib Cranes

Tags: Jib Cranes, Wall Mounted Cranes, Workshop Cranes

Volume pricing — save up to 12% Discount is calculated automatically on the cart subtotal.

Quantity	Discount
1 unit	—
2	−3%
3–4	−5%
5–9	−8%
10+	−12%

+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.

Configure your crane

Select capacity, span and options. Price, weight and shipping update live.

1 Max capacity — kg

2 Span — m

Type of use

Outdoor use unlocks weather-protection options: axis sealing, stainless-steel axis, hoist cover, 120µm C3 paint systems and hot-dip galvanizing.

Mounting kit

Auto-suggested KF level depends on capacity and span. Type A = belts on IPE/HEA/HEB or concrete post. Type C = clamps on IPE/HEA/HEB. FCM = wall mount with chemical anchors.

Chain hoist

Add a chain hoist to the crane, or supply your own.

Manual hoist capacity

Pick the RLD model. Only models that match the crane SWL are shown.

Manual hoist lift

Load chain length (hand chain is always 1 m shorter).

GIS GP electric chain hoist

Electric chain hoist — configuration

Every option in this panel belongs to the GIS GP electric chain hoist bundled with your jib crane. It is produced and invoiced as a separate item; the jib-crane options stay outside this panel.

Electric hoist — intensity of use

How will you use the electric hoist?

Each duty class has its own capacity envelope: the heavier the use, the lower the rated weight, so a heavier class may pull a larger GP sub-model. Selecting a class lighter than your real-world use voids the manufacturer warranty and risks motor failure.

GP electric hoist capacity

GP electric hoist lift height

Rotation locking

Mechanical lock to fix the boom in a position.

Beam trolley (manual / own hoist)

Plain (push) or geared beam trolley that carries the hoist along the jib boom. Standard-flange models fit all NZD IPE booms; geared trolleys ship with a 2.5 m hand chain (longer on request). Select 'No beam trolley' if you source it separately.

Hoist power supply (feeding line)

Galvanised rail with flat cable on trolleys that powers an electric chain hoist along the whole span — whether you buy the hoist here or supply your own. The mobile-pendant version adds two separate parallel rails so the 4-button control pendant travels independently of the hoist.

Rotation stops

Hard stops limiting boom rotation. Adjustable price depends on a-dimension.

Rotation slowing device

Damper to slow boom swing — installs without welding.

Hoist adjustable bumpers

Adjustable end stops for the hoist trolley, one pair for both boom extremities (beam width 91–300 mm).

Welded ring under the I-beam

Ring welded under the I-beam tip to hang a stationary hoist without a trolley.

Lockable main switch

20A lockable main switch under enclosure.

Standpipe (3 m)

3 m standpipe to host the main switch.

Paint system

Standard finish is 60µm C2 polyester powder, RAL 1028 yellow (included) — suitable for indoor use. For outdoor use pick a 120µm C3 system or hot-dip galvanizing.

Sealing of the axis

Weather sealing of the rotation axis for outdoor service.

Stainless steel axis

Rotation axis in stainless steel; price depends on the fixation number of your configuration.

Hoist cover (outdoor protection)

Sheet-metal protection clamped on the beam that shields the hoist from rain. Dimensions are adapted to the hoist.

Packaging

Standard packing is shrink film for road transport (not suitable for sea freight). Optional wooden transport support for spans up to 6 m.

Structural calculation note

Optional engineering document (note de calcul) certifying the structural reactions of your specific configuration. Required by some inspectors and insurers when commissioning the crane.

Delivery option

Express options shorten production by 1 or 2 weeks at a price premium.

Configuration —

Net price —

Quantity

Volume pricing — save up to 12 %

Quantity	Discount

Bundle promo: extra 3 % off when this order combines items from at least two product categories (e.g. a hoist + a jib crane).

Price breakdown

Net total (excl. VAT)	—

Estimated weight —
Lead time —
Mounting kit level —
Total height —

Shipping estimate

Delivery country

—

Enter your delivery country above to see an indicative freight estimate.

Need a tailored offer?

Send us your requirements through the quote form — this product will be prefilled and you can add more items in one request.

Request a quote

Low-profile wall jib crane for higher capacities in clearance-sensitive installations.

This equipment is manufactured to order and configured according to project-specific technical requirements.

Technical overview

Model / SKU: NZD
Product family: Wall Jib Cranes
Load capacity: 1000kg, 150kg, 1600kg, 2000kg, 2500kg, 250kg, 3200kg, 4000kg, 500kg
Span: 2000mm, 2500mm, 3000mm, 3500mm, 4000mm, 4500mm, 5000mm, 5500mm, 6000mm, 6500mm, 7000mm
Execution: Made to order
Project workflow: Quote-based engineering validation before production release

Send a quote request for final configuration, lead time and pricing.

Attributes

Weight	200 kg
Dimensions	200 × 20 × 50 cm
Load capacity	150kg, 250kg, 500kg, 1000kg, 1600kg, 2000kg, 2500kg, 3200kg, 4000kg
Span	2000mm, 2500mm, 3000mm, 3500mm, 4000mm, 4500mm, 5000mm, 5500mm, 6000mm, 6500mm, 7000mm
