- WLL = 500kg
- span = 2500mm
- height under beam HUB = 3000mm
- complies with EN 15011 (lifting class HC2, stability class S2)
- movable under load on smooth and clean ground
- total weight = 202kg
- weight of one foot = 70kg
- beam weight = 62kg
- beam width l = 91mm
- total height H = 3180mm (+30mm if power line)
- length between hoist stops L1 = 2090mm
- total length L = 2690mm
- total width E = 1500mm
- wheels Ø150mm
- polyester powder paint 60 microns equivalent category C2
