- WLL = 3200kg
- span = 7500mm
- height under beam HUB = 3500mm
- complies with EN 15011 (lifting class HC2, stability class S2)
- movable under load on smooth and clean ground
- total weight = 879kg
- weight of one foot = 200kg
- beam weight = 479kg
- beam width l = 170mm
- total height H = 3860mm (+30mm if power line)
- length between hoist stops L1 = 6780mm
- total length L = 7780mm
- total width E = 1500mm
- wheels Ø250mm
- polyester powder paint 60 microns equivalent category C2
