Electric walkie straddle stacker

Electric walkie straddle stacker is used to transport and manipulate pallet loads.
Electric warehouse pallet trucks are indispensable for optimizing warehouse and production processes, therefore they are reliable and energy efficient.

Structural and safety:

Load capacity: 1000kg (1t), 1200kg (1.2t), 1500kg (1.5t).
Lifting height: 1600mm (1.6m), 2500mm (2.5m), 3000mm (3m), 3300mm (3.3m), 3500mm (3.5m), 4500mm (4.5m), 5000mm (5m), 5600mm (5.6m).
Intelligent regenerative brake system and advanced AC control system.
Multi-function display with BDI and hour meter.
Electric stacker with emergency reversing device.
Auto deceleration system, therefore it utilizes regenerative braking.
Overloads are prevented via a built-in pressure relief valve for the trucks.
Emergency power disconnect switch.
Electric stacker with stepless speed control.
A lifting limit switch turns off the pump motor when it reaches max. height.
Standing driving system with a small turning radius and a motor that is dust-proof and water-proof.

Serviceability:

Technology reduces wiring complexity.
Side-way battery with roll-out system, in order to make it easy for replacement.

DELACCO electric walkie straddle stackers are compact and robust in order to ensure long-term use.

DELACCO has a wide selection of electric warehouse pallet trucks for sale.

Beginning with entry-level electric pallet stacker for light-duty applications and progressing to heavy-duty stackers powered by lead-acid or lithium-ion batteries.

Shipping Info

We organize delivery for all EU countries.

The current shipping price depends on several factors. The key factors are the dimensions and weight of the cargo, the route (place of loading/destination), the total distance, the delivery zone (urban areas, remote places, islands…) and the current price of fuel. In order to enable the fastest, most reliable and favorable transport of goods, we use the TIMOCOM Marketplace.
The prices shown below are indicative and non-binding. A separate transportation request is made for each order.

When choosing a carrier, all important criteria such as reliability, safety and availability are systematically checked, so that the most favorable price is not taken as a key factor.

For larger orders, the transport price should be more favorable than indicated in the table.
For the calculation, it is necessary to sum the values of W, H, Wt and D. The values of W, H, Wt and D vary depending on the length (L) of the load.

For all islands that are not connected to the mainland by road, +55% should be added to the displayed price.

The cost of transportation is charged just before delivery.

Additional information

Load capacity	1000kg, 1200kg, 1500kg
Lift height	1600mm, 2500mm, 3000mm, 3300mm, 3500mm, 4500mm, 5000mm, 5600mm
Initial lift	no
Engine type	AC
Folding platform	no
Electric power steering	no
Battery type/voltage/capacity	GEL/24/120, LA/24/200, LA/24/240, LA/24/300, LFP/24/225

Electric walkie straddle stacker EVV10-PV/EVV12-PV/EVV15-PV

Starting with a light-duty electric pallet stacker for entry-level applications and moving up to lead-acid or lithium-ion battery-powered heavy-duty stackers.
